Features
DISHWASHER-SAFE KNOBS
Whirlpool's cooktops feature easy-to-clean knobs that are dishwasher-safe to keep your cooktop looking like new.
HOT SURFACE INDICATOR LIGHT
A hot surface indicator light illuminates when the cooktop surface is still hot to the touch even after the heating element has been turned off.
EASY-WIPE CERAMIC GLASS COOKTOP
The ceramic glass cooktop provides an ideal space for cooking and easy cleanup.
FLEXHEAT™ DUAL RADIANT ELEMENT
Get two elements in one with a 6" inner ring that's great for smaller pots and pans and a 10" expandable outer ring that makes room for larger cookware.
WARM ZONE ELEMENT
Keep food warm while you're finishing the rest of the meal using this low-powered element.
WALL OVEN COMPATIBLE
Install this cooktop to work with a wall oven or on its own for added flexibility.
Specifications
General
Color
Black
Manufacturer Color
Black
Fuel Type
Electric
Type
Built-In
Cooktop
Burners/Elements
5
Power Output
• Left front: 3000W/1900W
• Left rear: 1200W
• Center rear: 100W
• Right front: 3000W/1900W
• Right rear: 1200W
• Left rear: 1200W
• Center rear: 100W
• Right front: 3000W/1900W
• Right rear: 1200W
Burner/Element Size
• Left rear: 6"
• Right rear: 6"
• Center rear: 6" (Warming)
• Left front: 6" / 10" (Dual)
• Right front: 6" / 10" (Dual)
• Right rear: 6"
• Center rear: 6" (Warming)
• Left front: 6" / 10" (Dual)
• Right front: 6" / 10" (Dual)
Elements
Smoothtop
Surface Features
Easy-Wipe ceramic glass cooktop
Features
Technologies
FlexHeat™ dual radiant element
Additional Information
• Infinite heat controls
• Heating element on indicator light
• Hot surface indicator light
• Warm zone element
• Dishwasher-safe knobs
• Wall oven compatible: can be installed over built-in oven
• Heating element on indicator light
• Hot surface indicator light
• Warm zone element
• Dishwasher-safe knobs
• Wall oven compatible: can be installed over built-in oven
Electrical Information
Information
• 208/240 V
• 40 A
• 60 Hz
• 40 A
• 60 Hz
Certifications and Approvals
ADA Compliant
Yes
Accessories
Optional
Power cord not included
Dimensions
Class Width
30"
Width
30.81 inch(es) / 78.26 cm
Height
5.25 inch(es) / 13.34 cm
Depth
21.75 inch(es) / 55.25 cm
Weight
41.01 lb(s) / 18.6 kg
Additional Dimensions
• Cutout Depth: 20-3/8"
• Cutout Width: 29-1/16"
• Cutout Width: 29-1/16"
Shipping Dimensions
Width
35 inch(es) / 88.9 cm
Height
9.25 inch(es) / 23.5 cm
Depth
25 inch(es) / 63.5 cm
Weight
46.01 lb(s) / 20.87 kg
Warranty
Warranty
Limited 1 Year Parts and Labor
UPC
UPC#
883049472706
